Podrobný popis
KEY FEATURE 80 PLUS Silver certified (230V EU) Support Intel ATX 3.0 standard (compatible with ATX 3.1) 120mm Fluid Dynamic Bearing (FDB) Fan Flat cable design Powerful single +12V rail OVP/OPP/SCP/UVP/OCP/OTP protection 3 years warranty (Adjusted according to different regions) Model GP-P550SS Type Intel Form Factor ATX 12V v3.0 (compatible with ATX 3.1) PFC Active PFC (>0.9 typical) Input Voltage 155-240 Vac Input Current 6.3A Input Frequency 50-60 Hz Output Capacity 550W Dimension 150 x 140 x 86 mm Fan Type 120mm Fluid Dynamic Bearing (FDB) fan 80 PLUS Silver Efficiency 90% at typical load (230V EU) MTBF >100,000 hours Protection OVP/OPP/SCP/UVP/OCP/OTP Power Good Signal 100-150ms Hold Up Time >16ms Cable Type Flat, All black Connectors ATX/MB 20+4 Pin x 1 : 600mm*1 CPU/EPS 4+4 Pin x 1 : 650mm*1 PCI-e 6+2 Pin x 2 : 600mm+120mm*1 SATA x 3 + 4 Pin Peripheral x 1 : 500mm+120mm+120mm+120mm*1 SATA x 2 + 4 Pin Peripheral x 2 : 500mm+120mm+120mm+120mm*1Dodatočné parametre
| Kategória: | Zdroje |
|---|---|
| Záruka: | 1116 dní |
| Hmotnosť: | 2 kg |
| EAN: | 4719331554187 |
| Výkon zdroja: | 500 - 550W |
| Formát: | ATX, E-ATX |
| Ventilátor [mm]: | 120 |
| Účinnosť [%]: | 90 |
| Výkon [W]: | 550 |
| SATA: | 7 |
| FDD: | 0 |
| Molex: | 0 |
| ATX12V 4+4pin: | 2 |
| PCI-E-6+2pin: | 1 |
| PFC filter: | Aktívny |
| Modulárna kabeláž: | Nie |
| Kategória: | PC zdroje |
| MPN: | GP-P550SS |
