Podrobný popis
NEX Level Power ELITE NEX N700 230V • Active PFC and a dual forward topology design • Excellent temperature resistance • High peak power tolerance • Durability, reliability, and safety • 75% efficiency • 3-year warranty ModelMPW-7001-ACBN-B ATX VersionATX 12V Ver. 2.41 PFCActive PFC Input Voltage200-240V Input Current5A Input Frequency50-60Hz Dimensions (L x W x H)140 x 150 x 86 mm Fan Size120mm Fan BearingSleeve Fan Efficiency? 75% @ Typical Load ErP 2014 Lot 3Yes Operating Temperature0-40°C Power Good Signal100 - 500 ms Hold Up Time?10ms at 100% load MTBF>100,000 Hours ProtectionsOVP / OPP / SCP / UVP / OTP / Inrush Protection RegulatoryTUV, CE, CCC, EAC, UKCA ATX 24 Pin Connectors1 EPS 8 Pin / 4+4 Pin Connectors2 SATA Connectors5 Peripheral 4 Pin Connectors3 PCI-e 6+2 Pin Connectors2 SeriesElite Series Category500 to 750W ModularNon Modular 80 Plus EfficiencyNone 80 PLUS Form FactorATX Watts700WDodatočné parametre
| Kategória: | Zdroje |
|---|---|
| Záruka: | 1116 dní |
| Hmotnosť: | 4.83 kg |
| EAN: | 4719512128374 |
| Výkon zdroja: | 700 - 900W |
| PFC filter: | Aktívny |
| Kategória: | PC zdroje |
| Modulárna kabeláž: | Nie |
| PCI-E-6+2pin: | 2 |
| ATX 20+4pin: | 1 |
| ATX12V 4+4pin: | 2 |
| Molex: | 3 |
| Účinnosť [%]: | 75 |
| SATA: | 5 |
| Výkon [W]: | 700 |
| Formát: | ATX, E-ATX |
| MPN: | MPW-7001-ACBN-BEU |
